Technical data:
With self-centering function.
•With 3-foot-operation pedals to work easier.
•With adjusting & calibrating functions in the 4 clamps on the turntable.
•Plastic protector special for mounts/demounts tool.
•Angle of mounts/demounts tool can be adjusted and calibrated..
•Assist arm AL-340(Optional).
•Clamping system with stepping function.
•Suitable for motorcycles.
TECHNICAL DATA
Power supply/Motor power | 110V/220V/380 1.1/0.75KW | Bead breaker force | 5500Lb （2500kg） |
Air supply | 6-10bar （0.6-1.0Mpa） | Max.Wheel diameter | 39″ （1000mm） |
Rim clamping range (External)first position | 6″-15″ （152mm-381mm） | Max.Wheel width | 13″ （330mm） |
Rim clamping range(Internal）first position | 8″-17″ （203mm-432mm） | Noise | <70dB |
Rim clamping range (External)second position | 12″-20″ （305-508mm） | N.W./G.W. | 381Lb/472Lb (173kg/214kg) |
Rim clamping range (Internal)second position | 12″-22″ （305-559mm） |
